Hydraulic Foot Clamp

The Hydraulic Foot clamp is capable of clamping 2″ to 6-5/8″ Rods/Casings. Adjustable to accepting every position of drill rods this unit is mounted on a fully floating support arm, which ensures that no weight is placed on the threads thus reducing premature wear.

Key Features

  • Fabricated steel base frame for greater strength.
  • Body Orifice – 9 inches.
  • Fabricated lever arms – no castings.
  • Adjustable connecting rod with Left- & Right-hand threads to allow accurate adjustment of jaw actuation.
  • Machined Jaw assemblies to suit most standard drill rod sizes.
  • Capable Of Accepting 2″ – 6 5/8″ Rod / Casing
  • The 3 Jaw design is self centering
  • Swings out of the way when not in use
  • Spring mount arm is interchangeable (dependant on orientation)
  • Quality hydraulic components used throughout
  • Hoses “bulk headed” to the spinner body for ease of hose replacement
  • Solid 4mm Steel Construction Including Locator Funnel
  • Replaceable carbide inserts, easily maintained.
  • Easily replaceable Inserts for NQ & HQ jaw sizes.
  • RC Slips Table, RC Slips holders and inserts to suit 3 1/2″, 4″ & 4 1/2″ rod sizes.
  • Inter-changeable with industry standard rod clamps.
